The BETAflam® 145 C-flex VFD V is specially designed for power supply connections to frequency converters.

The halogen free cable is made of class 5 tinned fine copper strands, both insulation and outer sheath are electron-beam cross-linked and has an increased environmental compatibility.

The cable has a good resistance to weathering, ozone, UV-rays and oil, suitable for outdoor use.

Very high resistance to temperature (up to +145ºC) and ageing as well as an EMC optimized braided shielding (coverage appr. 85%) The outer sheath is reinforced with fibres.

Fixed and flexible application in dry, humid and wet rooms. Good weather, ozone and UV resistance. Extensively oil resistant. Intended for installation outdoors. Typical areas of application are connections of:

• Lamps
• Heatingunits
• Electrical machinery (thermal class B)
• Switchboards / switchcabinets

MAIN CHARACTERISTICS

• 0,6 /1kV (1.8/3kV)
• Testing voltage 5000V
• Fixed -55°C up to +145°C
• Halogen free
• Flame retardant
• Non-flame propagating
• Low fire load
• Electron-beam cross-linked SHF2
• Reinforced
• EMC-optimized braided shielding (coverage appr. 85%

APPROVALS

The BETAflam® 145 C-flex VFD V has been approved according to:

• DNV-GL
