The BETAtrans® 3 GKW ENX FE180 C-flex is specially designed for use inside and outside of rail vehicles and buses. These cables maintain their function over a limited period in the event of a fire and are suitable for connecting fixed and moving parts such as emergency lamps, flue gas outlets and switchgear.
The halogen free cable is made of class 5 tinned fine copper strands, both insulation and outer sheath are electron-beam cross-linked and has an increased environmental compatibility.

Typical areas of application are connections of:

• Emergency lamps
• Flue gas outlets
• Switchgear

MAIN CHARACTERISTICS

• 0,6 /1kV
• Fixed -40°C up to +120°C
• Halogen free
• Flame retardant
• Non-flame propagating
• Low fire load
• Electron-beam cross-linked SHF2
• Circuit integrity
  • IEC 60331-21 up to 180 minutes
  • EN 50200       up to 120 minutes
• EMC-optimized braided shielding (coverage appr. 85%)

APPROVALS

The BETAtrans® 3 GKW ENX FE180 C-flex has been approved according to:

• DNV-GL
